Açıklama
Malzeme – Material 1.1213 (Cf53)
Sertlik – Hardness 62 ± 2 HRC
Isıl İşlem – Heat Treatment İndüksiyon (Induction)
DIN ISO 8404 – A
| a | d1 | d2 | I1 | I | Sipariş Kodu | Order Code |
|---|---|---|---|---|---|
| 3 | 10 | 12 | 4 | 40 | D01.01_10 40 |
| 3 | 10 | 12 | 4 | 60 | D01.01_10 60 |
| 3 | 10 | 12 | 4 | 80 | D01.01_10 80 |
| 3 | 10 | 12 | 4 | 100 | D01.01_10100 |
| 3 | 10 | 12 | 4 | 120 | D01.01_10120 |
| 6 | 12 | 16 | 4 | 40 | D01.01_12 40 |
| 6 | 12 | 16 | 4 | 60 | D01.01_12 60 |
| 6 | 12 | 16 | 4 | 80 | D01.01_12 80 |
| 6 | 12 | 16 | 4 | 100 | D01.01_12100 |
| 6 | 12 | 16 | 4 | 120 | D01.01_12120 |
| 6 | 12 | 16 | 4 | 140 | D01.01_12140 |
| 6 | 12 | 16 | 4 | 160 | D01.01_12160 |
| 8 | 16 | 20 | 7 | 40 | D01.01_16 40 |
| 8 | 16 | 20 | 7 | 60 | D01.01_16 60 |
| 8 | 16 | 20 | 7 | 80 | D01.01_16 80 |
| 8 | 16 | 20 | 7 | 100 | D01.01_16100 |
| 8 | 16 | 20 | 7 | 120 | D01.01_16120 |
| 8 | 16 | 20 | 7 | 140 | D01.01_16140 |
| 8 | 16 | 20 | 7 | 160 | D01.01_16160 |
| 8 | 16 | 20 | 7 | 180 | D01.01_16180 |
| 8 | 16 | 20 | 7 | 200 | D01.01_16200 |
| 8 | 18 | 22 | 7 | 60 | D01.01_18 60 |
| 8 | 18 | 22 | 7 | 80 | D01.01_18 80 |
| 8 | 18 | 22 | 7 | 100 | D01.01_18100 |
| 8 | 18 | 22 | 7 | 120 | D01.01_18120 |
| 8 | 18 | 22 | 7 | 140 | D01.01_18140 |
| 8 | 18 | 22 | 7 | 160 | D01.01_18160 |
| 8 | 18 | 22 | 7 | 180 | D01.01_18180 |
| 8 | 18 | 22 | 7 | 200 | D01.01_18200 |
| 8 | 18 | 22 | 7 | 240 | D01.01_18240 |
| 8 | 20 | 24 | 7 | 60 | D01.01_20 60 |
| 8 | 20 | 24 | 7 | 80 | D01.01_20 80 |
| 8 | 20 | 24 | 7 | 100 | D01.01_20100 |
| 8 | 20 | 24 | 7 | 120 | D01.01_20120 |
| 8 | 20 | 24 | 7 | 140 | D01.01_20140 |
| 8 | 20 | 24 | 7 | 160 | D01.01_20160 |
| 8 | 20 | 24 | 7 | 180 | D01.01_20180 |
| 8 | 20 | 24 | 7 | 200 | D01.01_20200 |
| 8 | 20 | 24 | 7 | 240 | D01.01_20240 |
| 15 | 22 | 26 | 7 | 80 | D01.01_22 80 |
| 15 | 22 | 26 | 7 | 100 | D01.01_22100 |
| 15 | 22 | 26 | 7 | 120 | D01.01_22120 |
| 15 | 22 | 26 | 7 | 140 | D01.01_22140 |
| 15 | 22 | 26 | 7 | 160 | D01.01_22160 |
| 15 | 22 | 26 | 7 | 180 | D01.01_22180 |
| 15 | 22 | 26 | 7 | 200 | D01.01_22200 |
| 15 | 22 | 26 | 7 | 220 | D01.01_22220 |
| 15 | 22 | 26 | 7 | 240 | D01.01_22240 |
| 15 | 22 | 26 | 7 | 300 | D01.01_22300 |
| 15 | 24 | 28 | 7 | 80 | D01.01_24 80 |
| 15 | 24 | 28 | 7 | 100 | D01.01_24100 |
| 15 | 24 | 28 | 7 | 120 | D01.01_24120 |
| 15 | 24 | 28 | 7 | 140 | D01.01_24140 |
| 15 | 24 | 28 | 7 | 160 | D01.01_24160 |
| 15 | 24 | 28 | 7 | 180 | D01.01_24180 |
| 15 | 24 | 28 | 7 | 200 | D01.01_24200 |
| 15 | 24 | 28 | 7 | 220 | D01.01_24220 |
| 15 | 24 | 28 | 7 | 240 | D01.01_24240 |
| 15 | 24 | 28 | 7 | 300 | D01.01_24300 |
| 15 | 30 | 36 | 7 | 100 | D01.01_30100 |
| 15 | 30 | 36 | 7 | 120 | D01.01_30120 |
| 15 | 30 | 36 | 7 | 140 | D01.01_30140 |
| 15 | 30 | 36 | 7 | 160 | D01.01_30160 |
| 15 | 30 | 36 | 7 | 180 | D01.01_30180 |
| 15 | 30 | 36 | 7 | 200 | D01.01_30200 |
| 15 | 30 | 36 | 7 | 220 | D01.01_30220 |
| 15 | 30 | 36 | 7 | 240 | D01.01_30240 |
| 15 | 30 | 36 | 7 | 300 | D01.01_30300 |
| 15 | 30 | 36 | 7 | 360 | D01.01_30360 |
| 15 | 40 | 48 | 10 | 160 | D01.01_40160 |
| 15 | 40 | 48 | 10 | 180 | D01.01_40180 |
| 15 | 40 | 48 | 10 | 200 | D01.01_40200 |
| 15 | 40 | 48 | 10 | 220 | D01.01_40220 |
| 15 | 40 | 48 | 10 | 240 | D01.01_40240 |
| 15 | 40 | 48 | 10 | 280 | D01.01_40280 |
| 15 | 40 | 48 | 10 | 300 | D01.01_40300 |
| 15 | 40 | 48 | 10 | 320 | D01.01_40320 |
| 15 | 40 | 48 | 10 | 360 | D01.01_40360 |
| 15 | 50 | 58 | 10 | 160 | D01.01_50160 |
| 15 | 50 | 58 | 10 | 200 | D01.01_50200 |
| 15 | 50 | 58 | 10 | 240 | D01.01_50240 |
| 15 | 50 | 58 | 10 | 300 | D01.01_50300 |
| 15 | 50 | 58 | 10 | 360 | D01.01_50360 |
